Work light - Ledson - Epix 20+ - Work Strobe - 20'' - Position light Red/Amber - 10 Flash patterns - Work / Scene

€364.95 (tax incl.)

€301.61 (tax excl.)

  • Reference: 334915124
  • Producttype: Work light
  • Dimensions (mm): 510 (w) x 43 (h) x 61 (d)
  • E-mark: yes
  • Position Light Color: Red/Amber
  • Strobe function: 10 Flash patterns
  • Strobe Approval: R65
  • Beam type: Work / Scene
  • Sales unit: Single item
  • Standard Delivery time: 1-3 business days
x
...Continue

Work-Scene Beam Pattern

Must-have accessories

Wiring Kit

Wiring kit - Ledson - 1 lamp - 6 pins - Deutsch DT - 12V

Wiring kit - Ledson - 1 lamp - 6 pins - Deutsch DT - 12V

€47.95
Quantity

Ledson Epix 20+ Work Strobe LED bar 20" 180W

What is delivered:

  • 1x Ledson Epix 20+ Work Strobe LED bar 20" 180W
  • Bolts and screws
  • Mounting instructions
  • DT cable: 6-pin (you also need a DT harness, available here)
  • Installation manual

Ledson Epix 20+ Work Strobe

The EPIX20+ Work Strobe is the work lighting bar that offers a modern look and delivers the performance to meet all conditions. With its impressive 180W, this bar provides work lighting with a range of 143 m at 1 lux and a wide light beam of 120°, ensuring maximum light coverage over a large area. With 11,800 actual lumens and a color temperature of 5000K, it offers strong and natural lighting that facilitates work under all conditions. Ledson's smart mounting brackets ensure that the bar can be mounted practically anywhere and in any desired way on the vehicle.

Features and technical specifications:

  • Position light with unique dynamic ignition, integrated into the reflector
  • Selectable position light in red or yellow/orange
  • 120° wide light beam
  • Range: 143 m (1 lux)
  • 15,500 lumens (theoretical), 11,800 lumens (actual)
  • Color temperature 5000K (white)
  • 180 W (18 x 15 W LEDs)
  • Voltage: 9-36V
  • IP69K (water/dustproof)
  • Aluminum housing and polycarbonate lens
  • Side reflective optics
  • Pressure equalization membrane
  • Electronic temperature management
  • DT connector (supplied)
  • 12 A at 12V and 5 A at 24V
  • E-marked ECE R148 (R1, SM1), R65, and R10 (EMC approved)
334915124 7323230050342

Data sheet

Accessory
Lighting
Producttype
Work light
Product serie
Epix
Serial model
20+
Version
Work Strobe
Series
Ledson Signal
Size ( Ø / ↔ )
2) Medium
Shape
Ledbar
Width (mm)
510
Height (mm)
43
Depth (mm)
61
Beam type
Work / Scene
Light type
LED
Lighting - Type
Reverse light
Signal light
Work light
Light color
White
Position light
Position light
Color of position light
Amber
Red
Signal lights
Flash light
Strobe function
10 Flash patterns
E-mark
yes
ECE approval
R23
R65
Glass color
Clear
Chrome / RVS
no
Housing color
black
Housing material
Aluminum
Lamp rim color
black
Lamp rim material
Aluminum
IP rating
IP69K
Light distance (m) at 1 lux
143
Voltage
12V
18V
24V
30V
36V
Watts
180W
LEDs per lamp
18
Wattage per LED
15W
number of pins
6 pins
Connector
Deutsch DT
Vehicle brand
Universal
Sales unit
Single item
Standard Delivery time
1-3 business days
prodcat1
M
Shipping Size
S

Specific References
