LED Light bar - Ledson - Epix 14+ - 14'' - Powerboost - Position light White/Amber - Driving

€209.95 (tax incl.)

€173.51 (tax excl.)

  • Reference: 334915088
  • Producttype: LED Light bar
  • Dimensions (mm): 357 (w) x 43 (h) x 61 (d)
  • E-mark: yes
  • Position Light Color: White/Amber
  • Beam type: Driving
  • Sales unit: Single item
  • Standard Delivery time: 1-3 business days
x
...Continue

Driving Beam Pattern

Quantity

Ledson Epix 14+ LED Bar 14" 120W Powerboost

What is included:

  • Mounting materials: Bolts and screws to secure the bar to a suitable surface
  • Mounting details
  • DT 4-pin cable (you also need a DT harness, available here)
  • Installation instructions

Dynamic Ignition and Performance of the Epix+ LED Bar

The dynamic ignition of the position lights gives the bar an effective start-up. Everything you need and want in an LED bar can be found in the Epix+. We have maximized performance in an E-approved mode, with the option for Powerboost when you choose to go “off-road.” Approved R65 flashers ensure your visibility while working on the road and keep you safe in any weather and at any time of day. Our self-developed smart mounting accessories ensure easy installation on almost any part of the vehicle, exactly as you want it.

Features and Technical Specifications:

  • Position light with unique dynamic ignition, integrated into the reflector
  • Selectable position light in xenon white or yellow/orange
  • Lighting pattern for driving light (wide and elongated)
  • E-approved R112, R7, R10 (EMC certified)
  • Range: 328 m (1 lux), Powerboost: 459 m (1 lux)
  • 9,800 lumens (theoretical), 7,300 lumens (actual)
  • Color temperature 5000K (Neutral White)
  • 120 W (8 x 15 W LEDs)
  • Voltage: 9-36V
  • IP69K (water/dust resistant)
  • Aluminum housing and polycarbonate lens
  • Side-reflecting optics
  • Pressure equalization membrane
  • Electronic thermal management
  • DT connector (included)
334915088 7323230047410

Data sheet

Accessory
Lighting
Producttype
LED Light bar
Product serie
Epix
Serial model
14+
Feature
Powerboost
Series
Ledson Signal
Size ( Ø / ↔ )
2) Medium
Shape
Ledbar
Width (mm)
357
Height (mm)
43
Depth (mm)
61
Beam type
Driving
Light type
LED
Lighting - Type
Driving Light
Light color
White
Position light
Position light
Color of position light
Amber
White
E-mark
yes
ECE approval
R10
R112
Glass color
Clear
Chrome / RVS
no
Housing color
black
Housing material
Aluminum
Lamp rim color
black
Lamp rim material
Aluminum
IP rating
IP69K
Light distance (m) at 1 lux
Range: 328 m (1 lux), Powerboost: 459 m (1 lux)
Voltage
12V
18V
24V
30V
36V
Watts
120W
LEDs per lamp
8
Wattage per LED
15W
number of pins
4 pins
Connector
Deutsch DT
Vehicle brand
Universal
Sales unit
Single item
Standard Delivery time
1-3 business days
