Ford Ranger 2023+ Raptor Lazer LED Grille Kit R16

€934.95
Tax included
Lazer GK-RAP-03K
Ford Ranger 2023+ Raptor Lazer LED Grille Kit R16
Lazer Grille Kits - Lighten up your grille
E-Approval E-approved
Sales unitSet
Delivery1-3 business days

Drive safe, please take care of local rules for lights and accessories


Choose your configuration below
Lazer LED Kit (click for options)
CAN Interface
Lazer CAN-LZR Can-Bus Contactless Reader (voor CAN-LZR)
Quantity

For an OE quality, auxiliary spotlight installation, the Lazer Grille Integration Kits include bespoke mounting brackets which allow for quick and easy fitting of Lazer High Performance LED Spotlights within the front grille of the most popular road cars, pick-up trucks, and light commercial vehicles. Designed to blend seamlessly within the original styling of each vehicle, the resulting lighting setup remains fully robust and secure.

The Ford Ranger Raptor kit, designed for model year 2023 vehicles, includes a pair of Triple-R 850 High Performance LED driving lights, plus wiring kit, alongside 4x brackets precision-engineered to engage perfectly with the standard centre grille on the vehicle, with added strength and security provided by the supplied self-tapping (plastic) screws. Made from a high strength composite material, known for its excellent strength and UV stability, the brackets are fully weather and chemical resistant to ensure your installation remains in great condition year after year.

Supplied alongside the mounting brackets are a set of cutting guides, designed to facilitate the installation and ensure a perfect fit every time, without removal of the vehicle’s grille or bumper parts.

The Ford Ranger Raptor Grille Integration Kit is carefully engineered and optimised for use with Triple-R 850 High Performance LED Spotlights. Our warranty does not cover grille mounts which are fitted with non-Lazer Lamps’ branded products.

Where the vehicle has Xenon or LED headlights as standard, it may not be possible to detect a 12V high beam signal. In these instances it will be necessary to complete the electrical installation using a Lazer CAN Interface. For advice on how to check for a 12V high beam signal, please click here.

WHAT'S INCLUDED

  • 1x Grille Mounting Kit
  • 2x Triple-R 850 LED Lamps
  • 1x Two-Lamp Wiring Kit
  • Installation Instructions

Bespoke vehicle integration kit for Lazer LED Spotlight installation

Custom fit for Ford Ranger Raptor (MY 2023)

Available with: Triple-R 850 High Performance LED Spotlights

Added option for integrated white and amber backlight function (white only approved for on-road use - Standard model only)

Kit also includes bespoke mounting brackets and two-lamp wiring kit

Cutting guides included

Brackets made from high strength, UV -stable, composite material

Fully road-legal

5-year warranty

Made in Britain



2x
Triple-R
850 Elite
(E-Boost Mode)

 2x
Triple-R 850
Voltage Range (DC) 10-32V 10-32V
LED Life 50,000 hrs 50,000 hrs
Weight 2.6 kg 2.6 kg
HIGH BEAM FUNCTION
Total Luminous Flux

16136 Lm

 13860 Lm
Total Driver 'FOV' Flux † 10634 Lm 8358 Lm
Colour Temperature 5000K 5000K
Number of High Output LEDs 2 x 6 2 x 6
Power Consumption 146 Watts 132 Watts
Current Draw (at 14.4V) 10.2 Amps 9.2 Amps
CERTIFICATION
High Beam ECE R112 ECE R112
ECE Reference

N/A
(17.5 x2 - E-Mark Mode)

 45 x2
Position Light (White only) N/A ECE R7
PHOTOMETRIC DATA
Horizontal Beam Angle 42° 19°
0.25 lx Line 1643m 1500m
0.5 lx Line 1162m 1061m
1 lx Line 822m 750m
3 lx Line 474m 433m

† Driver FOV flux is a measure of effective lumens taking consideration of the amount of light in a driver's 'field-of-view' defined as an area +/- 45o left/right, and +/- 10o up/down. For more information – click here.

GK-RAP-03K

Data sheet

Series
Lazer Integration Kits
E-mark
yes
ECE R112
Approved
Accessory
Lighting
Sales unit
Set
12 Volt
yes
Number of lights
2
Light color
white/xenon white
Shape
Ledbar short
Light type
LED
Brand
Ford
Country of Origin
United Kingdom
Standard Delivery time
1-3 business days
Electric Device
yes
