    Tail light - Ledson - Nano Fog - 3.5" - 9cm - Clear - Rev - Fog - 12V-36V
    Tail light - Ledson - Nano Fog - 3.5" - 9cm - Clear - Rev - Fog - 12V-36V
    Tail light - Ledson - Nano Fog - 3.5" - 9cm - Clear - Rev - Fog - 12V-36V
    Tail light - Ledson - Nano Fog - 3.5" - 9cm - Clear - Rev - Fog - 12V-36V Tail light - Ledson - Nano Fog - 3.5" - 9cm - Clear - Rev - Fog - 12V-36V
    Tail light - Ledson - Nano Fog - 3.5" - 9cm - Clear - Rev - Fog - 12V-36V

    Tail light - Ledson - Nano Fog - 3.5" - 9cm - Clear - Rev - Fog - 12V-36V

    €94.95(tax incl.)

    €78.47 (tax excl.)

    • Reference: 33490607
    • Producttype: Tail light
    • Dimensions (mm): 90 (w) x 20 (h) x 61 (d)
    • E-mark: Yes
    • Light Color: White/Red
    • Beam type: Work / Scene
    • Sales unit: Single item
    • Standard delivery time: 1-3 business days
    Combine subtle design with high performance using the ultra-compact Ledson Nano Fog reverse and rear fog light.
    ...Continue

    Work-Scene Beam Pattern

    Quantity :
    • Pay Pay in a secure environment
    • Questions Questions about this product? Our experts are here to help
    • 4.8/5 4.8/5 More than 10,000 customers have already gone before you

    Ledson Nano Fog Combined LED Reverse & Rear Fog Light (9-36V - 18W - IP69K)

    The Ledson Nano Fog is an ultra-compact combined LED light combining a powerful reverse light with a bright red rear fog lamp in one streamlined housing. Featuring an installation height of just 20 mm, the Nano Fog enables a discreet and versatile fitment without sacrificing illumination performance. The bright white work light output (1600 actual lumens, 5000K) covers a wide 140° beam angle for maximum rear visibility while reversing, while the vivid red fog light ensures high safety in harsh weather conditions.

    Fully certified to ECE R23 (reverse light) and ECE R148 (fog light), this heavy-duty aluminum housing light is built to endure demanding commercial use. Featuring an IP69K rating, it is impervious to high-pressure washing and dust ingress. Includes a 4-pin Deutsch DT connector for quick and reliable wiring on trucks, vans, trailers, and campers.

    Key Features & Benefits

    • ✔ 2-in-1 Dual Functionality: Combines an E-approved reverse light and rear fog light in one compact unit.
    • ✔ Ultra-Low Profile: Measures only 20 mm in height (90 x 20 x 61 mm) for clean and unobtrusive surface mounting.
    • ✔ High Light Output: Produces 2100 theoretical (1600 actual) lumens with a 140° wide beam pattern up to 42 meters (1 lux).
    • ✔ Fully E-Marked: Certified to ECE R23 for reverse signaling and ECE R148 for rear fog lighting on public roads.
    • ✔ IP69K Waterproof Build: Maximum protection rating against water, mud, and high-pressure jet washing.
    • ✔ EMC Shielded: Certified to ECE R10 and CISPR25 Class 2 to eliminate interference with vehicle electronics and radios.

    Specialist Advice from Douwe

    "The Nano Fog takes compactness to the next level by merging both reverse and fog light functions. With a height of just 20 mm, it fits practically anywhere on a truck chassis, trailer, or service van without sticking out, while delivering sharp 5000K white light and clear red fog signaling."

    About the manufacturer: Ledson

    Ledson is a premier Scandinavian vehicle lighting brand recognized for cutting-edge aesthetics, rugged durability, and strict adherence to European safety standards.

    Why buy from Lights And Styling?

    At Lights And Styling, you get access to top-tier commercial vehicle accessories, expert tailored advice, fast shipping, and outstanding customer care!

    Disclaimer

    This product is universally compatible with 9-36V vehicle systems. Always check local regulatory requirements concerning vehicle signal placement and reverse light positioning prior to installation.

    Ledson
    33490607

    Data sheet

    General: Accessory
    Lighting
    General: Producttype
    Tail light
    General: Product serie
    Nano
    General: Serial model
    Fog
    Dimensions and weight: Size ( Ø / ↔ )
    1) Compact
    General: Shape
    Rectangular / Oval
    Dimensions and weight: Width (mm)
    90
    Dimensions and weight: Height (mm)
    20
    Dimensions and weight: Depth (mm)
    61
    Dimensions and weight: Weight (kg)
    0.2
    Light and vision: Beam type
    Work / Scene
    Light and vision: Light type
    LED
    Light and vision: Lighting - type
    Fog light
    Reverse light
    Light and vision: Light color
    Red
    White
    Design and material: Glass color
    Clear
    Light and vision: Color temperature
    5000K
    Light and vision: Theoretical Lumens
    2100
    Light and vision: Effective Lumens
    1600
    Light and vision: Light distance (m) at 1 lux
    42
    certifications and delivery: E-mark
    Yes
    certifications and delivery: Certifications
    CISPR25-2
    R10
    R148
    R23
    Technical specifications: Voltage
    12V
    18V
    24V
    30V
    36V
    Technical specifications: Watts
    18W
    Technical specifications: LEDs per lamp
    6
    Technical specifications: Wattage per LED
    3W
    Technical specifications: Number of pins
    4 pins
    Technical specifications: Connector
    Deutsch DT
    Design and material: Housing color
    Black
    Design and material: Housing material
    Aluminum
    certifications and delivery: IP rating
    IP69K
    certifications and delivery: What is delivered
    1 light
    General manual
    Mounting frame
    fit and mounting: Mount
    Normal
    certifications and delivery: Sales unit
    Single item
    certifications and delivery: Standard delivery time
    1-3 business days
    Size in inches
    3.5
    Size in cm
    9
    Vehicle type
    Aanhanger
    ATV
    Box van
    Car
    Pickup
    Semi-Trailer
    Truck
    Van
    Prodcat1
    M
    Prodcat2
    AB
    Shipping Size
    Standard
    certifications and delivery: Warranty
    3 year
    certifications and delivery: IR-code
    a0.K21.st
    Additional information: Ideal for
    ATV
    Campers
    Trailer
    Trailer
    Trucks
    Vans
    Additional information: Target audience
    Fleet owners
    Mini-truckers
    Transportation companies
    Truckers
    Additional information: What does Douwe say?
    The Nano, but even more versatile thanks to the combination of a reverse light and a fog light. Compact and easy to install. So it fits anywhere!
    certifications and delivery: Manufacturer
    Ledson Lights AB | Bangatan 3 | 265 38 | Astorp | Sweden | www.ledsonlights.com | [email protected]

    Specific References

    UPC
    30
    EAN13
    7323230060570
    MPN
    0007-100-003355
