Work light - Ledson - Epix 14+ - Work Strobe - 14.1" - 35.7cm - Position light Red/Amber - 10 flash patterns - Work / Scene
€241.95(tax incl.)
€199.96 (tax excl.)
- Reference: 334915084
- Producttype: Work light
- Dimensions (mm): 357 (w) x 43 (h) x 61 (d)
- E-mark: Yes
- Strobe function: 10 flash patterns
- Beam type: Work / Scene
- Sales unit: Single item
- Standard delivery time: 1-3 business days
x
...Continue
Must-have accessoires
Wiring Kit
Ledson Epix 14+ Work Light
What is delivered:
Ledson Epix 14+ Work Light
Bolts and screws to attach the beam to the correct surface
Assembly details
DT cable 6-pin
Position lights
The bar is equipped with specially designed reflectors from the Epix series with dynamic ignition of the position lights. The color of the position lights can also be chosen between yellow/orange and red, which is also approved for road use.
Strobe lights
The Epix14+ Work Strobe is equipped with 10 different strobe patterns, one of which is ECE R65 approved. By simply linking two units together you can achieve both synchronous and asynchronous flash patterns between them. Use your Epix14+ Work Strobe LED light bar as a work light or reversing light (not R23 approved); the strobe turns off when activated and then resumes the previously selected flash pattern when you turn the work light off again.
Features and technical data:
- Position light with unique dynamic ignition, integrated in the reflector
- Selectable position light in red or yellow/orange
- 120° wide light pattern
- Range: 119 m (1 lux)
- 9'800 lumens (theoretical), 7'300 lumens (actual)
- Color temperature 5000K (Neutral White)
- 120 W (8 x 15 W LEDs)
- Voltage: 9-36V
- IP69K (water/dustproof)
- Aluminum housing and polycarbonate lens
- Side reflective optics
- Pressure equalization membrane
- Electronic heat management
- DT connector (included)
- 7.1A at 12V (3.6A in eco mode) and 3.5A at 24V (1.7A in eco mode)
- E-marked ECE R148 (R1, SM1), R65 and R10 (EMC approved)
Flash Patterns:
- Single flash sync: 2.2 Hz
- Single flash asynchronous: 2.2 Hz (when using 2 LED bars)
- Triple flash synchronization: 1.1 Hz
- Triple flash asynchronous: 1.1 Hz (when using 2 LED bars)
- Quad flash synchronization: 1.25 Hz
- Quadruple flash asynchronous: 1.25 Hz (when using 2 LED bars)
- Combination of one long and five short synchronization: 0.83 Hz
- Combination of one long and five short asynchronous: 0.83 Hz (when using 2 LED bars)
- Burst sync: 10 Hz
- Burst asynchronous: 10 Hz (when using 2 LED bars)
334915084
Data sheet
- General: Accessory
- Lighting
- General: Producttype
- Work light
- General: Product serie
- Epix
- General: Serial model
- 14+
- General: Version
- Work Strobe
- General: Series
- Ledson Signal
- Dimensions and weight: Size ( Ø / ↔ )
- 2) Medium
- General: Shape
- Ledbar
- Dimensions and weight: Width (mm)
- 357
- Dimensions and weight: Height (mm)
- 43
- Dimensions and weight: Depth (mm)
- 61
- Light and vision: Beam type
- Work / Scene
- Light and vision: Light type
- LED
- Light and vision: Lighting - type
- Reverse light
Signal light
Work light - Light and vision: Light color
- White
- design and material: Glass color
- Clear
- Light and vision: Position light
- Position light
- Light and vision: Color of position light
- Amber
Red - Lights and vision: Signal lights
- Flash light
- Light and vision: Strobe function
- 10 flash patterns
- Lights and vision: Light distance (m) at 1 lux
- 49
- certifications and delivery: E-mark
- Yes
- certifications and delivery: Certifications
- R23
R65 - Technical specifications: Voltage
- 12V
18V
24V
30V
36V - Technical specifications: Watts
- 120W
- Technical specifications: LEDs per lamp
- 8
- Technical specifications: Wattage per LED
- 15W
- Technical specifications: Number of pins
- 6 pins
- Technical specifications: Connector
- Deutsch DT
- design and material: Chrome / RVS
- No
- design and material: Housing color
- Black
- design and material: Housing material
- Aluminum
- design and material: Lamp rim color
- Black
- design and material: Lamp rim material
- Aluminum
- certifications and delivery: IP rating
- IP69K
- fit and mounting: Vehicle brand
- Universal
- certifications and delivery: Sales unit
- Single item
- certifications and delivery: Standard delivery time
- 1-3 business days
- Size in inches
- 14.1
- Size in cm
- 35.7
- Prodcat1
- M
- Shipping Size
- Standard
- certifications and delivery: IR-code
- a8.D13.st
Specific References
- UPC
- 1
- EAN13
- 7323230050328
Unboxing Ledson Epix 14
Ledson Epix 14+ Work Light
