LED Light bar - Viklight - Ymer 10 - 11'' - Position light White/Amber - Driving

€179.95 (tax incl.)

€148.72 (tax excl.)

  • Reference: VLY10EM2
  • Producttype: LED Light bar
  • Dimensions (mm): 277 (w) x 41 (h) x 53 (d)
  • E-mark: yes
  • Position Light Color: White/Amber
  • Beam type: Driving
  • Sales unit: Single item
  • Standard Delivery time: 4-7 business days
x
...Continue

Driving Beam Pattern

Quantity

New Viklight Ymer 2.0. The ramp has now been fitted with a modern standing position light in a choice of orange or white.

-E-marked as extra light
-Double fixing system, stepless rail and side feet.
-Only 40.5 mm high, light and easy to install
-Good light output, 1 lux at 480 meters!
-Comprehensive polycarbonate to avoid paint loss due to stone chips

Ymer 2.0 is our thinnest LED ramp to date with only 40.5mm height, which together with the very low weight makes it easy to mount. The ramp can be mounted both standing and hanging.

E-approved for use as an auxiliary light on the road and the reference number of 50 provides good light length, Ymer 10-inch provides a lux of 480 meters!
Ymer has a light pattern that extends the vehicle's regular high beam.

Viklight Ymer has a fully curved polycarbonate lens that protects the paint from stone chips and facilitates water runoff.
This LED lightbar is covered by a full three-year warranty!

What else do I need?
The lightbar does not include its own wiring kit but the DT connector of the lightbar fits with our DT wiring kit.
The cable set includes a fuse, relay and switch.

The LED lightbar has two different mounting systems included to facilitate installation, a stepless rail at the rear of the lightbar and L-shaped metal feet for mounting on the short sides.

Data LED Extra Light Ramp Viklight Ymer 10-inch 2.0:
Lamp body: Aluminum
Mounting: Side-mounted feet with 360-degree adjustability included. Ymer can be mounted hanging and standing.
Ventilating membrane according to the Gore-Tex principle releases any condensation.
Number of LEDs: 6 x 10 watt LG LED (60W)
Number of lumens: 5800 theoretical
Light length with 1 lux: 480 meters
E-marked: Yes, ECE R112, R7
EMC: ECE R10
Voltage: 9-36 volts DC
Power consumption: 5 Amp at 12 v
Color temperature: approx. 6000 K
Light pattern: Spot beam
IP class: IP68, IP69K withstands weather and wind.
Length: 277 mm
Height excl. mounting bracket: 40.5 mm
Height incl. mounting bracket: 55.5 mm
Depth: 52.5 mm
Lens: Polycarbonate

WLTP information
WLTP weight: 1 kg
WLTP frontal area: 0.002 (m2)

3 years warranty.

NOTE: Sold individually.

Viklight
VLY10EM2

Data sheet

Accessory
Lighting
Producttype
LED Light bar
Product serie
Ymer
Serial model
10
Size ( Ø / ↔ )
2) Medium
Shape
Ledbar
Width (mm)
277
Height (mm)
41
Depth (mm)
53
Weight (kg)
1
Beam type
Driving
Light type
LED
Lighting - Type
Driving Light
Light color
White
Position light
Position light
Color of position light
Amber
White
Color temperature
6000K
E-mark
yes
ECE approval
R7
R10
R112
Glass color
Clear
Chrome / RVS
no
Housing color
black
Housing material
Aluminum
Lamp rim color
black
Lamp rim material
Aluminum
Product color
black
IP rating
IP68
IP69K
Mount
Normal
Lumen
5800
Light distance (m) at 1 lux
480
Voltage
12V
18V
24V
30V
36V
Watts
60W
LEDs per lamp
6
Wattage per LED
10W
number of pins
4 pins
Connector
Deutsch DT
Wiring included
No
Sales unit
Single item
Standard Delivery time
4-7 business days
prodcat1
M
Prodcat2
AB
Shipping Size
S
